Hyundai B1475: Driver Curtain Airbag (CAB) Circuit Short To Ground
Is your scanner showing Hyundai B1475?
No worries. We'll show you what it means and how to deal with it.
Hyundai B1475: Driver Curtain Airbag (CAB) Circuit Short To Ground
OVERVIEWWhat Does The Hyundai B1475 Code Mean?
Curtain Airbag (hereinafter referred to CAB) is located at driver and passenger side of headliner It protects passenger’s head and shoulder from fragments of glass or something sharpen caused by overturn. CAB consists of air bag and inflator. Air bag reduces impact of collision by filling up gas. Inflator keeps gas and uses it to deploy air bag on collision.
The SRSCM sets DTC B1475 if there is a short to ground in DCAB harness. *In this case, SRSCM checks if there’s any fault in circuit by sending current for a while.
What Are The Potential Causes Of The Hyundai B1475 Code?
- Short to ground in CAB harness.
- Poor connection of connected part.
- Poor connection between shorting bar and release pin.
- Faulty CAB.
- Faulty SRSCM.
Recommended Parts
Below are some recommended auto parts to help you address the trouble code affecting your vehicle and get it running smoothly again:
>>> WORKPRO 582-piece Crimp Terminals, Wire Connectors, Heat Shrink Tube, Electrical Repair Kit
>>> SRS Control Module
>>> Hyundai Driver Curtain Airbag
Note: During the purchasing process, please check carefully whether the part you want to buy fits your car!
Reference Sources
SRSCM (SRS Control Module) General Information for B1475 – Hyundai Genesis Coupe, pages 206-212.
