Dodge P1004: Short Runner Valve Control Performance

Is your scanner showing Dodge P1004?
No worries. We'll show you what it means and how to deal with it.

Presented by

Randy Worner

00:00/00:00

Dodge P1004: Short Runner Valve Control Performance

OVERVIEW

Severity

Medium

DIY Difficulty Level

Intermediate

Repair Cost

$80-$320

Can I Still Drive?

Yes (Short-term only)

What Does The Dodge P1004 Code Mean?

The engine performance and power output is enhanced through the use of the Short Runner Valve (SRV) system. The SRV system allows the intake charge air to bypass the long Intake Manifold runners between the Intake Manifold plenum and the Intake Manifold interface to the cylinder heads by providing a shorter runner directly between the plenum and the cylinder head interface The SRV position is controlled by a pneumatic/spring actuator and electronic solenoid valve.

When the solenoid is not energized (the “rest” position), the SRV is held in the closed position. When the solenoid is energized the SRV is moved and held in its opened position. There is a set of enable conditions including a minimum engine coolant and ambient temperature, SRV enable and Powertrain Coordinator load enable condition. If any of these conditions are not met, then the SRV valve is de-energized (closed).
