Chrysler B1C2B: Right Side Seat Thorax Squib 1 Low
Is your scanner showing Chrysler B1C2B?
No worries. We'll show you what it means and how to deal with it.
Chrysler B1C2B: Right Side Seat Thorax Squib 1 Low
OVERVIEWWhat Does The Chrysler B1C2B Code Mean?
The ORC sends out a 40 mA diagnostic current on each squib voltage supply circuit at power up and every 500 ms thereafter while the ignition is in on. This DTC sets when the ORC detects a short to ground on the squib circuit for more than 2.5 seconds. This DTC transitions from active to stored when the module sees a recovery from a short to ground for greater than 2.5 seconds.
What Are The Potential Causes Of The Chrysler B1C2B Code?
- (R6) right seat thorax squib 1 line 2 circuit shorted to ground
- (R8) right seat thorax squib 1 line 1 circuit shorted to ground
- Right seat thorax airbag
- Occupant restraint controller (ORC)
