Acura P1077: Intake Manifold Tuning (IMT) Valve Stuck in High RPM Position
Is your scanner showing Acura P1077?
No worries. We'll show you what it means and how to deal with it.
Acura P1077: Intake Manifold Tuning (IMT) Valve Stuck in High RPM Position
OVERVIEWWhat Does The Acura P1077 Code Mean?
When the PCM sends a close (long runner) command, no long runner return signal is received for at least 7 seconds. Execution is once per drive cycle, engine speed, 3,600 rpm and intake air temperature a minimum of 5 ºF (-15 ºC).
NOTE: Before you troubleshoot, record all freeze data and any on-board snapshot.
What Are The Potential Causes Of The Acura P1077 Code?
- Poor connections or loose terminals at the IMT actuator and the PCM
- “Open” circuitbetween the PCM and the IMT actuator
- Faulty IMT actuator
- PCM may need to be updated with the latest software
- Faulty PCM
